Lightweight low step-thru’ frames, with suspension forks and wide range gears will let you explore your local terrain. Gel saddles with elastomer shock absorbers, ergonomically shaped grips and comfort pedals ensure you’ll enjoy a smooth ride. New, larger diameter 27.5″ wheels are lightweight and roll along easier, but retain our low stand over clearance.
- Lightweight HydroFormed alloy frame with integrated head tube
- 27.5″ wheels with fast rolling tyres
- Shimano 18sp gearing with easy to use twist shifters
- Light alloy double wall rims, stainless spokes and alloy stem
Specifications
|
Model |
Storm 27-1 |
|
Frame |
6061 Alloy, women's specific with integrated headtube and replaceable dropout |
|
Travel |
48mm Travel |
|
Fork |
1 1/8th Ahead Suspension Fork, alloy crown |
|
Headset |
1 1/8th Ahead Internal semi cartridge |
|
Rear Derailleur |
Mircoshift RD-M21L 6sp |
|
Shifters |
Microshift Shift MS25-6R 6-Speed, |
|
Brake Levers |
Alloy adjustable |
|
Brakes |
Alloy V-Brake |
|
Crankset |
3-piece steel, with 38T chain ring & double chainguard |
|
BB-Set |
MTB Std BB |
|
Handlebar |
Steel Riser, 620mm x 60mm rise |
|
Grips |
MTB Kraton egonomic |
|
Stem |
Zoom Alloy ahead, 90mm, w/alloy cap |
|
Pedals |
Resin Platform with ball bearings |
|
Seatpost |
Steel 27.2 x 300mm, alloy QR |
|
Seat |
Womens MTB comfort with Elastomer/Gel |
|
Hub (Front) |
Fr: Steel 32H QR |
|
Hub (Rear) |
Rr: Steel 32H nutted |
|
Wheelset |
Alloy 32H Double Wall |
|
Chain |
KMC Z-51 |
|
Cassette |
LX 14-28T 6-Speed Freewheel |
|
Spokes |
Stainless Steel |
|
Rims |
Alloy 32H Double Wall |
|
Tires |
MTB fast rolling 27.5 x 1.95 |
|
Extras |
Kickstand |
Geometry
|
|
Size |
XS |
S |
M |
L |
|
A |
Seat Tube Length (C-Top) Inches |
13.0 |
14.5 |
16.5 |
18.7 |
|
|
Seat Tube Length (C-Top) mm |
330 |
370 |
425 |
475 |
|
B |
Horizontal Top Tube Length mm |
530 |
551 |
570 |
589 |
|
C |
Head Tube Length mm |
100 |
100 |
105 |
110 |
|
D |
Head Angle deg |
68.0 |
68.0 |
68.0 |
70.0 |
|
E |
Seat Angle deg |
75.0 |
73.5 |
73.0 |
73.0 |
|
|
BB Drop mm |
47 |
47 |
47 |
47 |
|
F |
Chainstay Length mm |
440 |
440 |
440 |
440 |
|
G |
Wheelbase mm |
1063 |
1066 |
1081 |
1080 |
